1100L × 2 Underground Garbage Containers
Item No.: HDD-4
Capacity: 1100L × 2 (standard wheelie bins)
Inlets: Triple inlets (opening shape/size customizable)
Overall Size: 4242 × 1804 × 2945 mm
Underground Size: 4070 × 1632 × 2085 mm
Ground Size: 4242 × 1804 × 855 mm
Product Description
Built for demanding outdoor and semi-outdoor locations, this underground garbage container hides the containers and lift set below ground, leaving only a clean, durable top platform and two inlets at street level. The sealed chamber curbs odor and pests, cuts secondary pollution, and avoids summer rot and winter freeze issues. With two inlets and two 1100L wheelie containers, peak-hour users are spread out, queues shrink, and the site stays tidy. Appearance, signage, and functional add-ons are configurable and can tie into smart-sanitation systems for overflow sensing, smoke/temperature alarms, automatic fire suppression, deodorization, and remote telemetry.
HD also provides other capacities for underground garbage containers. Please contact us or view the product category page: Underground Trash Containers.
Specifications
Item No.: HDD-4
Capacity: 1100L × 2 (standard wheelie bins)
Inlets: Triple inlets (opening shape/size customizable)
Structure & Materials: Above grade—2 mm stainless-steel platform and inlet assembly; below grade—120 channel-steel frame and lift platform with anti-corrosion treatment
Drive & Control: Hydraulic lift; supports 24/48V DC or 220V AC per local electrical standards; button/sensor/card control available
Sealing & Drainage: Flanged platform with sealing gaskets; automatic drainage at the pit bottom
Collection Interface: Raise to grade and tow bins out; compatible with common collection vehicles
Features
- Subsurface, sealed architecture: Hidden chamber delivers a neat streetscape while sealing and drainage mitigate leaks and odors.
- No special trucks: Standard 1100L bins and existing routes—lift, tow, return, and resume service.
- Built to last outdoors: 2 mm stainless steel up top paired with a 120-channel steel underframe for long-term durability.
- Dual-inlet efficiency: Two entry points spread foot traffic, reduce wait times, and limit stray litter.
- Smart options ready: Add overflow detection, smoke/temperature alarms, auto fire suppression, and mist/biological deodorization with remote notifications.
Why Choose Us?
- Policy-aligned delivery: End-to-end support—from scheme and civil interface to manufacturing, installation, training, and after-sales—with full documentation for acceptance.
- Operational savings: Sealed collection cuts cleaning cycles and odor complaints; platform data enables route tuning and work-order closure.
- Code-compliant electrics: 24/48V DC or 220V AC per local standards; interfaces and wiring prepared for smooth inspection and approval.
- Configure without overspend: Choose only the modules you need—sensor entry, overflow, fire, deodorization, remote monitoring/GPS—to keep CAPEX and OPEX in check.
- Proven compatibility: Works with standard 1100L containers and typical fleet vehicles; minimal change to field operations.
Customize Options
- Colors & Signage: RAL or custom colors, sorting icons, multilingual labels
- Opening & Control: button/foot/sensor/card access with role management
- Functional Modules: weighing, overflow alerts, smoke/temperature alerts, automatic fire suppression, mist/biological deodorization, inlet locking, remote monitoring/GPS, data interface
- Container Options: compatible with 660L, 240L, 1100L and others per project
- Documentation Package: pit/embed references, installation & maintenance manuals, acceptance documentation, and training
